Master Data and Façades

Master Data and Façades


This post is tenth part in a series about building and adopting a modern streaming data integration platform. In this post I will discuss how to release the master data locked in legacy systems, such as mainframes.

When modernizing the architectures, some issues tend to repeat. One of such issues is how to provide access to legacy systems, such as mainframes, that hold important master data. Legacy systems are typically being phased out, and it is difficult to justify building new, complex integrations to those systems. But we still mechanisms to access the data and the logic in them, while those systems are still running.

One common way is to create a façade in front of the legacy system, emulating the APIs of the modern system. The API calls in the façade are implemented by using calls to the legacy system. Then you gradually replace the calls to the modern implementation.

The modern implementation should have the same API as the façade, so you need to put effort in the design of the API. When all the API calls have been implemented by the modern system, the façade is no longer needed. This is called the Strangler Fig pattern, a name popularized by Martin Fowler.

Original Strangler Fig pattern

When the façade is used to stream data, we need a little bit more complex pattern. Often mainframe systems cannot stream changes, so the intermediate system often needs to pull database dump from the legacy system, compare the result to the previous data dump, and then create a series of changes based on the differences.

As the intermediate system is more complex, a façade is not really an adequate name for it. Here we call it a “temporary modern system”, because it often contains some of the functionality of the modern system, but might be replaced by a more permanent modern system later.

Streaming Strangler Fig pattern

In the original Strangler Fig pattern, the programming language choice is not very important. You can also use an integration platform for this purpose. Basically, you need to carry out the API calls to the legacy system, and translate data into more modern format, often JSON. Most modern programming languages support this. However, in the streaming version of the Strangler Fig pattern, you need more complex data manipulation, as well as a way to store the data. It is also beneficial if you can easily build user interfaces for manipulating some data entities.

Low coding platforms, such as Outsystems, have recently gained popularity. These platforms promise to make software development more productive. This is often understood to mean that the software development will be cheaper. This would decrease the pressure on tight IT budgets. Some platforms even claim to empower “citizen developers”. Are these platforms well suited for building systems for Streaming Strangler?

The underlying idea of low coding is not new. During 80s and 90s, there was a similar development, under the name Fourth Generation Languages (4GL). 4GL languages were contrasted with Third Generation Languages (3GL), the traditional programming languages popular at the time, such as C, Pascal, COBOL, and so on.

Multiple kinds of 4GL products existed. Some succesful 4GL environments revolved around “graphical” design tool to quickly create forms. One popular such product was Oracle Forms. Also, there existed 4GLs that used text-based “programming language”, such as Progress 4GL. However, the promised revolution, where 4GL would replace 3GL, never materialized.

Ultimately, 4th generation languages were judged to be less capable than 3rd generation languages. For example, Progress 4GL name was changed to “OpenEdge Advanced Business Language in order to overcome a presumed industry perception that 4GLs were less capable than other languages.” 1

Experienced developers and architects are often suspicious of promises of order-of-magnitude improvements in software development productivity. As the saying goes, there is “No Silver Bullet” 2. The lesson from 4GL languages is that there is a hidden cost related to the promised productivity.

In trivial exmples, the low coding platforms may show promising productivity improvements. But once you implement non-trivial applications, such as in our use case, you start to encounter the limitations of the platform. To bypass the limitations, you need to develop complex work-arounds that will offset any cost savings from the initial development phase, and cause lots of developer frustration. Low coding platforms may also have much higher licensing costs.

Often up to 80% of the TCO of a system comes from the maintenance. Another large contributor to the TCO is knowing what to develop. The latter cost is often not fully included in the calculations, because some of it happens outside the software development project. One example are the failed iterations of the project. Several methods to reduce the cost and risk related to knowing what to do have emerged, such as making wireframes, user interface prototypes, incremental development methods, requirement specifications etc.

Low coding platforms may help, for example they may allow developing inexpensive prototypes. But an alternative approach can provide the same benefits without the limitations of the commercial low coding platforms.

Some open source web frameworks have survived over time, and matured to include the benefits of low coding platforms, with some key benefits over them.

Firstly, there are no licensing costs in developing or running applications with these frameworks, as these frameworks are open source. Secondly, these languages expose the underlying general programming language and provide extensibility in a way that low coding platforms cannot do.

The most popular web frameworks are Django and Ruby on Rails. Rails is currently more popular for building websites, but Django has a few clear benefits for our Streaming Strangler Fig pattern use case.

Django uses the Python programming language, while Rails uses Ruby. Python has very high market share in data manipulation tasks in general, and data sciences in particular, especially in enterprises. Python is the most popular programming language according to TIOBE 3, while Ruby is 19th.

Django also has very good database schema migration framework, simple mechanism for building REST APIs, and build-in admin UI for basic data manipulation tasks.

Django hits the sweet spot for building the intermediate temporary system needed in our Streaming Strangler Fig pattern.
